Centro Survey Store, Ltd.

The New ProSpector 3 Max Handheld XRF Analyzer Available for Sale!

ProSpector 3 Max is the next-generation handheld X-ray fluorescence analyzer. It offers a new level of analysis accuracy, speed, and detection limits. ProSpector 3 Max is the smallest and lightest XRF gun on the market with an intuitive and user-friendly software interface. Unique processing algorithms allow analyzing in various fields of application: PMI, Alloys, Precious metals, Archeometry, Petrochemical, Soils, Plastics, Automotive catalysts etc.

Accuracy
With powerful hardware and unique software algorithms, the ProSpector 3 offers the highest precision and accuracy of elemental analysis for a wide range of materials

Speed
Dynamically Adaptive Shaping (DAS) DPP developed by Elvatech combined with the Fast SDD detector makes the ProSpector 3 the fastest handheld XRF analyzer on the market

Stability
Thanks to the digiX-50 digital X-Ray source, automatic temperature and barometric corrections, and digital calibration adjustment, ProSpector 3 offers long-life reproducibility of the analysis without the need to re-calibrate the system

Features:

High speed of operation @ above 500 000 CPS count rate
Ambient temperature and pressure corrections for highest stability
Over 10 hours operation from the battery
Detector protection
Extensive and editable alloy grade library
Protective film replacement with no tool required
Full compatibility with ElvaX PC software
Radiation safety: IR proximity sensor and low count detection

Specifications:

Digital X-Ray Source digiX-50:

Anode: Rh, W
Voltage: 50 kV
Current: 200 uАmp
Power: 5 W
8 positions filter changer
2 position collimator changer

X-Ray Detector:

Type: Fast SDD
Area: 25 mm2 (option 70 mm2)
Energy resolution: <140 eV @ 5.9 keV
Count rate: 500,000 cps

Electronics:

DPP: proprietory DAS (Dynamically Adaptive Shaping) type, 80 MHz sampling rate
MCA: 4096 channels
Display: 4.3″
Connectivity: USB, Bluetooth, Wi-Fi
2 high-resolution video cameras

General:

Dimensions: 236 х 193 х 68 mm
Weight: 0.82 kg, 1.05 with battery kg
Protection: IP67

Software:

Operating system: Windows EC7
Analysis algorithms: Fundamental parameters (FPA), Empirical (regression)
